The X Series represents our most advanced technology and performance level.  No compromise, no kidding. The X5 and X3, as well as the new X4, have similar designs that are scaled for different room sizes and perform equally well. The ultimate drivers and component parts provide world-class speed and realism in an elegant design.

Compare Models
LF12 & LF15

Spatial LF12 and
LF15 Active Subwoofers

Like the M50, the LF12 and LF15 drivers from Spatial Audio Lab are cast frame, paper cone drivers utilized in the X Performance Series speakers. What sets these drivers apart is that they are driven by their own Hypex DSP controlled plate amplifier. Both the LF12 (X5) and LF15 (X3) can provide clean, quick and authoritative bass down to 25Hz. On both the X3 and X5 the plate amplifier is configured in-house so there is no need to be concerned about crossover points or phase controls. Simply turn the volume to the desired level.

M50 Midrange Driver

Spatial M50 Midrange Driver

Our new 12 - inch midrange driver is lightning quick by virtue of its low moving mass and powerful rare-earth motor design for excellent frequency response down to 90Hz. Specifically designed for open air applications, this driver delivers a natural timbre throughout the mid-band frequencies. Unlike other materials commonly used, our paper cone driver affords the least colored music reproduction possible. The M50 Midrange Driver opens the window to the best mid-band performance you have ever experienced.

Ultralam baffle

UltraLam Baffle

This high performance baffle material from Germany is a composite of hundreds of layers of beech glued together to form a beautiful and dense baffle with excellent self-damping properties. A secondary sub-baffle provides resonance draining properties and houses the isolated mid/high passive crossover and integrated N-Core power amplifier which drives the subwoofer.

X Series HF Driver

State of the Art AMT Driver

The world’s finest Air Motion Transformer manufactured by Beyma reproduces the upper midrange to ultrasonic frequencies in a single unit exhibiting low distortion and controlled directivity. This dipolar driver’s intrinsic high efficiency and large surface area provide unparalleled upper register reproduction eliminating listener fatigue while maintaining true fidelity to the input signal. The driver is made of machined and die cast aluminum construction along with a powerful Neodymium motor assembly providing precise imaging and soundstage.

Comparison Chart

The X5 provide clear, precise sound with excellent audio definition. With a wide frequency response and a high sensitivity rating, the X5 is a perfect fit for medium sized rooms.
X5 Black
X5 White
X5 Graphite

X5

$ 8,500 USD
Buy
X4 Ultralam
The X4 is the first all-passive X Series model engineered to provide clear, precise sound with excellent audio quality. With a linear frequency response and Dipolar operation, the X4 is a perfect fit for medium-sized rooms.
X4 White
X4 Graphite

X4

$ 7,950 USD
Buy
X3 Ultralam
X3 Black
The X3 provide clear, precise sound with excellent audio quality. With a precision frequency response and a high sensitivity rating, the X3 is a perfect fit for large rooms. Isoacoustics Gaia II feet included.
X3 Graphite

X3

$ 10,000 USD
Buy

Tech Specs

42"
Height
16"
Width
10"
Depth
Size
8W to 200W
Amplifier Use

Compatible with solid state and tube amplifiers
8 Watts up to 200 Watts

X Room use & Weight
Room use & Net Weight

Medium sized rooms 95 lbs (each)

Sensitivity
97dB
Sensitivity
Nominal
Impedance
25Hz - 20kHz
Frequency Range
Midrange driver
LF Driver

Spatial S50, 12" paper composite subwoofer, Ceramic motor

Midrange driver
Mid Driver

Spatial M50, 12" paper composite midrange, Neo motor

X Series HF Driver
HF Driver

Studio-grade Air Motion Transformer, 80 degree front pattern, Dipolar

Type
Type

Active-Passive Hybrid 3-way, Dynamic dipolar radiator

45"
Height
16"
Width
10"
Depth
Size
8W to 200W
Amplifier Use

Compatible with solid state and tube amplifiers
20 Watts up to 200 Watts

X Room use & Weight
Room use & Net Weight

Medium sized rooms 100 lbs (each)

Sensitivity
93dB
Sensitivity
Nominal
Impedance
32Hz- 20kHz
Frequency Range
Midrange driver
LF Driver

Spatial BR12, 12" paper composite woofer, Ceramic motor

Midrange driver
Mid Driver

Spatial BR12, 12" paper composite mid woofer, Ceramic motor

X Series HF Driver
HF Driver

Studio-grade Air Motion Transformer, 80 degree front pattern, Dipolar

Type
Type

Passive 2.5-way, Dynamic dipolar radiator

52"
Height
18"
Width
10"
Depth
Size
8W to 200W
Amplifier Use

Compatible with solid state and tube amplifiers
8 Watts up to 200 Watts

X Room use & Weight
Room use & Net Weight

Large rooms  90 lbs (each)

Sensitivity
97dB
Sensitivity
Nominal
Impedance
25Hz- 20kHz
Frequency Range
Midrange driver
LF Driver

Spatial ST15, 15" paper composite Subwoofer, Neo motor

Midrange driver
Mid Driver

Spatial M50, 12" paper composite midrange, Neo motor

X Series HF Driver
HF Driver

Studio-grade Air Motion Transformer, 80 degree front pattern, Dipolar

Type
Type

Active-Passive Hybrid 3-way, Dynamic dipolar radiator
